Onkyo TX-RZ50 vs Onkyo TX-RZ740

Here we are comparing Onkyo TX-RZ50 to Onkyo TX-RZ740 to reveal their common strengths and weaknesses as well as the differences between them which will help you in making a correct decision before the purchase. Both receivers have 9 channel amplifiers with Onkyo TX-RZ50's being more powerful.

Onkyo TX-RZ50	Onkyo TX-RZ740
Onkyo TX-RZ50 was introduced in 2021. It is equipped with 9 channel amplifier with 120 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven) power per channel and is capable of 11.2 maximum channel processing. It supports Dolby Atmos and DTS:X, passes 8K/60Hz and 4K/120Hz and upscales 1080p to 4K/8K and 4K to 8K video signal.	Onkyo TX-RZ740 was introduced in 2019. It is equipped with 9 channel amplifier with 100 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven) power per channel and is capable of 11.2 maximum channel processing. It supports Dolby Atmos and DTS:X, passes 4K/60Hz and upscales 1080p to 4K video signal.

We evaluated Onkyo TX-RZ50 and Onkyo TX-RZ740 and gave them scores of 93 and 91 out of 100 recpectively. Our ranking system is based on the amplifier specifications, audio and video features, connectivity, multizone capabilities, radio and many other details.

For more details about the ranking please go to    Evaluations section.

This section shows those features and specifications which are the reason to choose Onkyo TX-RZ50 over Onkyo TX-RZ740.

	Onkyo TX-RZ50	vs	Onkyo TX-RZ740
Higher Power Output	120 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven)	vs	100 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven)
More Advanced Auto Speaker Calibration System	Dirac Live™ and AccuEQ Room Corrections	vs	AccuEQ Advance with AccuReflex™
HDR10+		vs
Enhanced Audio Return Channel (eARC)		vs
QMS		vs
Auto Low Latency Mode Pass-through		vs
VRR		vs
QFT		vs
Video Signal Passthrough	up to 8K/60p (RGB/YCbCr4:4:4)	vs	up to 4K/60p (RGB/YCbCr4:4:4)
Video Signal Upscaling	1080p to 4K/8K and 4K to 8K	vs	1080p to 4K
Works with Amazon Alexa		vs
More 8K Inputs	7	vs
More Speaker Terminals	11	vs	9
More Large Speaker Terminals	11	vs	9
Bigger Power Supply	850 W	vs	750 W
Higher Power Output (8 Ω, 20 Hz - 20 kHz, 2 channel driven, FTC)	120 W (0.08% THD)	vs	100 W (0.08% THD)
Higher Power Output (6 Ω, 1 kHz, 1 channel driven, JEITA)	250 W (10% THD)	vs	225 W (10% THD)
Wi-Fi Standard	IEEE 802.11 a/b/g/n/ac	vs	IEEE 802.11 a/b/g/n

This section shows those features and specifications which are the reason to choose Onkyo TX-RZ740 over Onkyo TX-RZ50.

	Onkyo TX-RZ50	vs	Onkyo TX-RZ740
Higher DAC Specs	192 kHz/24 Bit	vs	384 kHz/32 Bit
Music Playback via USB	FLAC, WAV, Apple Lossless, WMA, MP3, DSD, AIFF, AAC	vs	FLAC, WAV, Apple Lossless, WMA, MP3, DSD, AIFF, AAC, Dolby TrueHD
High Resolution Audio Formats via USB	FLAC, WAV, Apple Lossless, DSD, AIFF, AAC	vs	FLAC, WAV, Apple Lossless, DSD, AIFF, AAC, Dolby TrueHD
More RCA Line Inputs	6	vs	7 (1 Front)
Front A/V Inputs	HDMI	vs	HDMI, Mini-Jack

We already listed pros and cons of each model. However, you may also find useful to look at their common strengths and weaknesses shown side-by-side.

STRENGTHS	Onkyo TX-RZ50	Onkyo TX-RZ740
THX™ Certification	Select™ (previously known as Select2)	Select™ (previously known as Select2)
Channel Processing	11.2	11.2
Dolby Atmos
Dolby Atmos Height Virtualization
DTS:X
IMAX Enhanced
DSD via HDMI	2-ch/Multi-ch Input	2-ch/Multi-ch Input
Auto Speaker Calibration System with Mic.	Dirac Live™ and AccuEQ Room Corrections	AccuEQ Advance with AccuReflex™
HDR10
Dolby Vision
New HDCP Version	2.3	2.3
Analog To HDMI Upconversion	Component**, Composite	Component**, Composite
Wi-Fi
Bluetooth	SBC, AAC, aptX, aptX HD	SBC, AAC
Chromecast Built-In
Many HDMI Inputs	7 (1 front)	7 (1 front)
USB Input	1 (Rear)	1 (Rear)
Many RCA Line Inputs	6	7 (1 Front)
Phono Input
RCA Pre-Outs	11.2 (barter to Zone 3 Pre/Line Out)	11.2 (barter to Zone 3 Pre/Line Out)
Composite Video Inputs	2	2
Component Video Inputs	1	1
Ethernet
Zones	3	3
Analog Tuner	FM/AM	FM/AM
Pandora
Spotify
Tidal

WEAKNESSES	Onkyo TX-RZ50	Onkyo TX-RZ740
No Front Wide Channel Support
No Auro 3D with Auro-Matic Upmixer
No Digital Radio

Onkyo TX-RZ50	Onkyo TX-RZ740
9 channel Linear Class A/B Amplifier: Onkyo TX-RZ50 features 9 channel power amplifier with Linear Class A/B design. It is rated at 120 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven) and is able to drive 4 ohm speakers.	9 channel Amplifier: Onkyo TX-RZ740 features 9 channel power amplifier. It is rated at 100 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven) and is able to drive 4 ohm speakers.

• Dynamic Audio Amplification: Onkyo TX-RZ50 and Onkyo TX-RZ740 feature Dynamic Audio Amplification which is Onkyo’s amplification philosophy that focuses on capturing the energy and dynamism contained in the audio signal and reproducing it without loss. Audio signals are not static like a test tone, but rather a countless collection of constantly moving waves. While static measurements such as S/N ratio and Total Harmonic Distortion are important, Onkyo believes that excellent dynamic and transient response is the key to emotionally involving sound. Dynamism - the “life” in music - is achieved when the amp can respond to changes in the signal instantaneously, so notes start and stop naturally and the nuances in attack, decay, sustain, and release are voiced with conviction. Onkyo home theater receivers represent the culmination of almost 70 years’ experience in amplifier design. The unique elements of their amplification system comprise high-current, low-impedance architecture to accurately control large speaker cones while enabling instantaneous response to dynamic changes, and discrete wide-range amplifier circuit topology to eliminate phase shift for clear and accurate audio imaging.

THX™ Select™ (previously known as Select2) certification

Onkyo TX-RZ50 and Onkyo TX-RZ740 are THX™ Select™ (previously known as Select2) certified. This means that they are made for medium sized rooms, up to 2,000 cubic feet in size, with a 10-12 foot viewing distance from the screen.

AMPLIFIER	Onkyo TX-RZ50	Onkyo TX-RZ740
Channels	9.2	9.2
Power Output	120 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven)	100 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven)
Front Wide Channel Support
Dynamic Audio Amplification
Non-Phase Shift Amplifier	Original 2-stage
VLSC (Vector Linear Shaping Circuitry)	Front L/R Channels	Front L/R Channels
THX™ Certification	Select™ (previously known as Select2)	Select™ (previously known as Select2)
Continuous 6 Ω Rated
Certified 4 Ω Performance
Discrete Output Stage Circuitry
Independent Block Construction (Amp/Preprocessor)
Bi-amp Capability
BTL (Bridged Transless or Bridging)

Onkyo TX-RZ50's and Onkyo TX-RZ740's amplifiers can be assigned for different speaker configurations.

• Dolby Atmos Configurations: The following speaker configurations are supported for Dolby Atmos:
Onkyo TX-RZ50: 5.2.2, 5.2.4, 7.2.2 with internal amplifier and 7.2.4 with addition of external 2 channel amplifier.
Onkyo TX-RZ740: 5.2.2, 5.2.4, 7.2.2 with internal amplifier and 7.2.4 with addition of external 2 channel amplifier.
• DTS:X Configurations: The following speaker configurations are supported for DTS:X:
Onkyo TX-RZ50: The speaker configurations for DTS:X are the same as for Dolby Atmos - 5.2.2, 5.2.4, 7.2.2 with internal amplifier and 7.2.4 with addition of external 2 channel amplifier.
Onkyo TX-RZ740: The speaker configurations for DTS:X are the same as for Dolby Atmos - 5.2.2, 5.2.4, 7.2.2 with internal amplifier and 7.2.4 with addition of external 2 channel amplifier.
• Configurations without height channels: There are also other speaker configurations available which do not include height channels:
Onkyo TX-RZ50: 5.2, 7.2 with internal amplifier.
Onkyo TX-RZ740: 5.2, 7.2 with internal amplifier.
• 2-ch Bi-Amp: Both models are able to bi-amp up to 2 main channels simultaneously. During bi-amplification two amplifiers are used for one speaker. One amplifier powers the midrange and tweeter section of the speaker and another amplifier powers the low frequency woofers. Each amplifier is less loaded and performs better. In order to use this feature speakers must have 2 pairs of connectors.

Dolby Atmos

Onkyo TX-RZ50 and Onkyo TX-RZ740 support Dolby Atmos.

• Dolby Surround Upmixer: Both models support Dolby Surround Upmixer. If the content is not mixed in Dolby Atmos then the Dolby surround upmixer will expand the audio to all channels including ceiling speakers. The upmixer has replaced the Dolby Pro Logic II family with improved upmixing algorithms.
• Dolby Atmos Height Virtualization: Both models support Dolby Atmos Height Virtualization which is a digital signal processing solution that leverages Dolby's deep understanding of human audio perception to create the sensation of overhead sound from the listener-level speakers.

DTS:X

Onkyo TX-RZ50 and Onkyo TX-RZ740 support DTS:X.

• DTS Neural:X: Both models feature DTS Neural:X which is an advanced upmixer that can take non DTS:X content and upmix it to the DTS:X speaker layout. It has replaced the DTS Neo family with improved flexibility.
• DTS Dialog Control: Both models have DTS Dialog Control. This function adjusts the dialog levels during playback of the DTS:X stream. It allows you to separately increase the dialog levels in contrast with the background sound and hear dialog easily even under noisy circumstances.

IMAX Enhanced

Onkyo TX-RZ50 and Onkyo TX-RZ740 are IMAX Enhanced certified. To qualify for IMAX Enhanced certification, 4K HDR televisions, projectors, sound bars, a/v receivers, loudspeakers, powered subwoofers and other premium home entertainment devices must meet carefully prescribed performance requirements established by IMAX, DTS and Hollywood's leading experts.

• What makes an IMAX Enhanced A/V receiver different from an A/V receiver with DTS:X technology? DTS:X technology is commonly found in most multi-channel A/V receivers on the market today. All IMAX Enhanced A/V receivers include DTS:X technology and deliver additional features, such as auto-sensing of IMAX Enhanced content, via IMAX Mode. IMAX Mode indicates that your A/V receiver supports fully immersive IMAX signature sound.

AUDIO DECODING	Onkyo TX-RZ50	Onkyo TX-RZ740
Dolby Atmos
Dolby Atmos Height Virtualization
Dolby Atmos Music
Dolby TrueHD
Dolby Digital Plus
Dolby Surround Upmixer
Dolby Pro Logic
Dolby Digital EX
THX Listening Modes
DTS:X
DTS Neural:X
DTS Virtual:X
DTS Neo
DTS-HD Master Audio
DTS-HD High Resolution Audio
DTS 96/24
DTS Express
DTS-ES
IMAX Enhanced
Auro 3D with Auro-Matic Upmixer

Onkyo TX-RZ50 comes with 7 HDMI 2.1 inputs with 8K support. It has 2 outputs - 1 Main and 1 Sub/Zone2.

Onkyo TX-RZ740 comes with 7 HDMI inputs. It has 2 outputs - 1 Main and 1 Sub/Zone2.

• 8K/60Hz and 4K/120Hz Passthrough on Onkyo TX-RZ50: All inputs pass up to 8K/60p (RGB/YCbCr4:4:4) video signal.
  4K/60Hz Passthrough on Onkyo TX-RZ740: All inputs pass up to 4K/60p (RGB/YCbCr4:4:4) video signal.
• 8K Upscaling on Onkyo TX-RZ50: It can upscale 1080p to 4K/8K and 4K to 8K from HDMI and analog sources.
  4K Upscaling on Onkyo TX-RZ740: It can upscale 1080p to 4K from HDMI and analog sources.
• Analog To HDMI Upconversion: Both receivers support analog to HDMI Upconversion, so you can input your analog video sources and output them digitally via HDMI. This means that you will need only one HDMI cable to connect to your TV.
• BT.2020 Color Space: BT.2020 or Rec. 2020 is a color standard which delivers a wider color gamut compared to Rec. 709. It covers approximately 75% of the total visual spectrum while the Rec. 709 covers only 35% (available on both models).
• HDCP 2.3 Copy Protection: Both receivers are HDCP 2.3 compliant which is a requirement for 4K/HDR copy-protected content transmission.
• Quick Media Switching (QMS): With HDMI 2.1a, Quick Media Switching for movies and video uses the HDMI VRR mechanism to eliminate the blackout period when an HDMI Source device switches its video mode. As long as the resolution remains the same and only the frame rate changes, QMS will instantly switch between frame rates. QMS eliminates A/V blackouts by using VRR technology to change frame rates, allowing instant changes from 24Hz to 60Hz frame rate, and anywhere in-between. The viewer never sees blank screens and gets a seamless experience (available on Onkyo TX-RZ50 only).
• 3D Ready: Both receivers are able to pass 3D video through HDMI.

HDR (High Dynamic Range)

Onkyo TX-RZ50 supports HDR10, HDR10+, Dolby Vision and Hybrid Log-Gamma.

Onkyo TX-RZ740 supports HDR10, Dolby Vision and Hybrid Log-Gamma. High dynamic range video has greater dynamic range than standard dynamic range (SDR) video with brighter whites and deeper blacks. The result is greater contrast and more details in dark and bright areas, better color and depth.

Enhanced Audio Return Channel (eARC)

Onkyo TX-RZ50 supports Audio Return Channel (ARC) which allows the compatible TV to send audio signal to the a/v receiver through the same HDMI cable which is used to send audio and video signals to the TV. So one HDMI cable is used to transfer audio signal in both directions. New Enhanced ARC will support uncompressed audio formats such as Dolby Atmos, DTS:X, Dolby TrueHD and DTS HD Master Audio whereas the previous ARC could support only Dolby Digital, Dolby Digital Plus, DTS, DTS HD, and PCM.

Gaming Features

Onkyo TX-RZ50 supports Auto Low Latency Mode (ALLM), Variable Refresh Rate (VRR) and Quick Frame Transport (QFT) for lag-free and smooth gaming.

VIDEO FEATURES	Onkyo TX-RZ50	Onkyo TX-RZ740
HDR10
HDR10+
Dynamic HDR
BT.2020 color space
Dolby Vision
HLG (Hybrid Log Gamma)
HDBaseT Compatible
Enhanced Audio Return Channel (eARC)
HDCP Version	2.3	2.3
QMS (Quick Media Switching)
ALLM (Auto Low Latency Mode)
VRR (Variable Refresh Rate)
QFT (Quick Frame transport)
3-D Ready
Video Signal Passthrough	up to 8K/60p (RGB/YCbCr4:4:4)	up to 4K/60p (RGB/YCbCr4:4:4)
Video Signal Upscaling	1080p to 4K/8K and 4K to 8K	1080p to 4K

TERMINALS	Onkyo TX-RZ50	Onkyo TX-RZ740
HDMI Inputs	7 (1 front)	7 (1 front)
HDMI Outputs	2 (1 Main, 1 Sub/Zone2)	2 (1 Main, 1 Sub/Zone2)
8K Inputs	7
USB Input	1 (Rear)	1 (Rear)
USB DC Out Port
Optical Inputs	1	1
Optical Outputs
Coaxial Inputs	1	1
RCA Line Inputs	6	7 (1 Front)
RCA Line Outputs
XLR Line Inputs
Phono Input
Multi-Channel Input
RCA Pre-Outs	11.2 (barter to Zone 3 Pre/Line Out)	11.2 (barter to Zone 3 Pre/Line Out)
XLR Pre-outs
Composite Video Inputs	2	2
Composite Video Outputs
S-Video Inputs
S-Video Outputs
Component Video Inputs	1	1
Component Video Outputs

GENERAL	Onkyo TX-RZ50	Onkyo TX-RZ740
Brand	Onkyo	Onkyo
Model	TX-RZ50	TX-RZ740
Type	A/V Receiver	A/V Receiver
Country	North America	North America
Release Year	2021	2019
Predecessor	Onkyo TX-RZ840	Onkyo TX-RZ730

AMPLIFIER	Onkyo TX-RZ50	Onkyo TX-RZ740
Channels	9.2	9.2
Power Output	120 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven)	100 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven)
Front Wide Channel Support
Amplifier Design	Linear Class A/B
Dynamic Audio Amplification
Non-Phase Shift Amplifier	Original 2-stage
VLSC (Vector Linear Shaping Circuitry)	Front L/R Channels	Front L/R Channels
THX™ Certification	Select™ (previously known as Select2)	Select™ (previously known as Select2)
Continuous 6 Ω Rated
Certified 4 Ω Performance
Discrete Output Stage Circuitry
Independent Block Construction (Amp/Preprocessor)
Bi-amp Capability
BTL (Bridged Transless or Bridging)

AUDIO FEATURES	Onkyo TX-RZ50	Onkyo TX-RZ740
Digital Signal Processing (DSP) Engine	32-bit Digital Signal Processing Engines	32-bit Digital Signal Processing Engines
DAC		AKM AK4458
DAC Specs	192 kHz/24 Bit	384 kHz/32 Bit
Maximum Channel Processing	11.2	11.2
Air Studios Monitor Certification
Dolby Atmos
Dolby Atmos Height Virtualization
Dolby Atmos Music
Dolby TrueHD
Dolby Digital Plus
Dolby Surround Upmixer
Dolby Pro Logic
Dolby Digital EX
THX Listening Modes
DTS:X
DTS Neural:X
DTS Virtual:X
DTS Neo
DTS-HD Master Audio
DTS-HD High Resolution Audio
DTS 96/24
DTS Express
DTS-ES
IMAX Enhanced
Auro 3D with Auro-Matic Upmixer
PCM	2-ch/Multi-ch Input	2-ch/Multi-ch Input
Network Audio Formats	FLAC, WAV, Apple Lossless, WMA, MP3, DSD, AIFF, AAC, LPCM	FLAC, WAV, Apple Lossless, WMA, MP3, DSD, AIFF, MPEG-4 AAC, LPCM
Music Playback via USB	FLAC, WAV, Apple Lossless, WMA, MP3, DSD, AIFF, AAC	FLAC, WAV, Apple Lossless, WMA, MP3, DSD, AIFF, AAC, Dolby TrueHD
High Resolution Music Playback via USB and/or Network	up to 192 kHz	up to 192 kHz
High Resolution Audio Formats via USB	FLAC, WAV, Apple Lossless, DSD, AIFF, AAC	FLAC, WAV, Apple Lossless, DSD, AIFF, AAC, Dolby TrueHD
Gapless Playback
DSD via HDMI	2-ch/Multi-ch Input	2-ch/Multi-ch Input
DSD via USB	2-ch Input	2-ch Input
DSD to PCM Converter
USB DAC
Jitter Reduction	PLL (Phase Locked Loop) Jitter-Cleaning Circuit Technology for S/PDIF Audio	PLL (Phase Locked Loop) Jitter-Cleaning Circuit Technology for S/PDIF Audio
DTS Dialogue Control
Dialog Enhancement
Dialog normalization
Dialogue Lift
Tone Control	All Channels	All Channels
Compressed Music Enhancer	Advanced Music Optimizer	Advanced Music Optimizer (bluetooth included)
High-resolution Music Enhancer
THX Processing Mode
Audyssey Dynamic EQ
Audyssey Dynamic Volume
Audyssey LFC
Audyssey Sub EQ HT
Audyssey DSX
Direct Mode
Pure Audio Mode
Pure Direct Analog Path Mode
Virtual Speakers	T-D (Theater-Dimensional)	T-D (Theater-Dimensional)
Independent Subwoofer Outputs

CALIBRATION	Onkyo TX-RZ50	Onkyo TX-RZ740
Auto Speaker Calibration System with Mic.	Dirac Live™ and AccuEQ Room Corrections	AccuEQ Advance with AccuReflex™

VIDEO FEATURES	Onkyo TX-RZ50	Onkyo TX-RZ740
HDR10
HDR10+
Dynamic HDR
BT.2020 color space
Dolby Vision
HLG (Hybrid Log Gamma)
HDMI Version	2.1
HDBaseT Compatible
Enhanced Audio Return Channel (eARC)
HDCP Version	2.3	2.3
QMS (Quick Media Switching)
ALLM (Auto Low Latency Mode)
VRR (Variable Refresh Rate)
QFT (Quick Frame transport)
3-D Ready
Video Signal Passthrough	up to 8K/60p (RGB/YCbCr4:4:4)	up to 4K/60p (RGB/YCbCr4:4:4)
Video Signal Upscaling	1080p to 4K/8K and 4K to 8K	1080p to 4K
Analog To HDMI Upconversion	Component**, Composite	Component**, Composite
Component Video Upscaling
Analog to Analog Video conversion
Component Video Maximum Resolution	480i/576i	480i/576i
isf Certified Calibration Control

CONNECTIVITY	Onkyo TX-RZ50	Onkyo TX-RZ740
Wi-Fi
Bluetooth	SBC, AAC, aptX, aptX HD	SBC, AAC
Works with Amazon Alexa
Google Assistant
Chromecast Built-In
Apple Siri
Works with SonoS
DTS Play-Fi	via Onkyo Music Control app	via Onkyo Music Control app
MHL Input
AirPlay	AirPlay 2	AirPlay 2 after firmware update
Apple Product Connection	iPod, iPhone and iPad	iPod, iPhone and iPad
Remote App	Onkyo Controller and Music Control apps	Onkyo Onkyo Controller and Music Control apps
InstaPrevue Input Source Prevue

TERMINALS	Onkyo TX-RZ50	Onkyo TX-RZ740
HDMI Inputs	7 (1 front)	7 (1 front)
HDMI Outputs	2 (1 Main, 1 Sub/Zone2)	2 (1 Main, 1 Sub/Zone2)
8K Inputs	7
USB Input	1 (Rear)	1 (Rear)
USB DC Out Port
Optical Inputs	1	1
Optical Outputs
Coaxial Inputs	1	1
RCA Line Inputs	6	7 (1 Front)
RCA Line Outputs
XLR Line Inputs
Phono Input
Multi-Channel Input
RCA Pre-Outs	11.2 (barter to Zone 3 Pre/Line Out)	11.2 (barter to Zone 3 Pre/Line Out)
XLR Pre-outs
Composite Video Inputs	2	2
Composite Video Outputs
S-Video Inputs
S-Video Outputs
Component Video Inputs	1	1
Component Video Outputs
Ethernet
Ethernet Switch
PC In
Front A/V Inputs	HDMI	HDMI, Mini-Jack
Speaker A/B
Headphone Out	6.3 mm (1/4")	6.3 mm (1/4")
Detachable Power Cord
uport

ZONES	Onkyo TX-RZ50	Onkyo TX-RZ740
Number of Zones	3	3
Powered Zones	2 and 3	2 and 3
Zone 2 Outs	HDMI, RCA Pre/Line Out (shared with Zone B Line out)	HDMI, RCA Pre/Line Out (shared with Zone B Line out)
Zone 3 Outs	RCA Pre/Line Out	RCA Pre/Line Out
Whole House Mode
RS-232C Interface
+12V Trigger Output	1 (MAIN, 100 mA)	1 (MAIN, 100 mA)
Remote (IR) Input/Output	1 / 0	1 / 0

MISCELLANEOUS	Onkyo TX-RZ50	Onkyo TX-RZ740
On-Screen Display	Graphical User Interface with Overlaid On-Screen Display (OSD) via HDMI	Graphical User Interface with Overlaid On-Screen Display (OSD) via HDMI
GUI Languages	7	7
IP Control
ONKYO-RI System Control
RIHD (Remote Interactive Over HDMI)
Smart Grid-Ready

RADIO	Onkyo TX-RZ50	Onkyo TX-RZ740
Analog Tuner	FM/AM	FM/AM
Presets	40	40
Digital Radio
Internet Radio	TuneIn	TuneIn
Pandora
Spotify
Tidal
Deezer
Napster
SiriusXM

CONSTRUCTION	Onkyo TX-RZ50	Onkyo TX-RZ740
Solid Aluminum Front
Speaker Terminals	11	9
Large Speaker Terminals	11	9
Color-Coded Speaker Terminals
Transparent High-Grade Speaker Terminals
Gold plated RCA terminals

POWER	Onkyo TX-RZ50	Onkyo TX-RZ740
Power Supply	AC 120 V, 60 Hz	AC 120 V, 60 Hz
H.C.P.S. (High Current Power Supply)	Custom High-Current Low-Noise Power Transformer	Customized Transformer
Toroidal Transformer
Power Consumption	850 W	750 W
No Sound Power	75 W	75 W
Standby Power	0.1 W	0.15 W
ECO Mode / Hybrid Standby Function

PHYSICAL	Onkyo TX-RZ50	Onkyo TX-RZ740
Dimensions (W x H x D)	435 mm x 201.5 mm x 398 mm 17-1/8" x 7-15/16" x 15-11/16"	435 mm x 177 mm x 379.5 mm 17-1/8" x 6-15/16" x 14-15/16"
Dimensions of Package (W x H x D)	570 mm x 335 mm x 490 mm 22-7/16" x 13-3/16" x 19-5/16"	534 mm x 265 mm x 468 mm 21" x 10-7/16" x 18-7/16"
Weight	14 kg (30.9 lbs)	10.8 kg (23.8 lbs)
Weight of Package	17.0 kg (37.5 lbs)	13.5 kg (29.8 lbs)

SPECIFICATIONS	Onkyo TX-RZ50	Onkyo TX-RZ740
Power Output (8 Ω, 20 Hz - 20 kHz, 2 channel driven, FTC)	120 W (0.08% THD)	100 W (0.08% THD)
Maximum Effective Power Output (6 Ω, 1 kHz, 1 channel driven, JEITA or IEC)	250 W (10% THD)	225 W (10% THD)
Dynamic Power per Channel (3 Ω, Front)	250 W	250 W
Dynamic Power per Channel (4 Ω, Front)	220 W	220 W
Dynamic Power per Channel (8 Ω, Front)	130 W	130 W
THD	0.08% (20 Hz - 20 kHz, Half power)	0.08% (20 Hz - 20 kHz, Half power)
Input Sensitivity and Impedance (Line)	200 mV/47 kΩ	200 mV/47 kΩ
Input Sensitivity and Impedance (Phono MM)	3.5 mV/47 kΩ	3.5 mV/47 kΩ
Rated Preout Level and Impedance	1 V/470 Ω	1 V/470 Ω
Rated Headphone Power Output	85 mW (32 Ω, 1 kHz, 10% THD)	85 mW (32 Ω, 1 kHz, 10% THD)
Phono Overload	70 mV (MM, 1 kHz 0.5%)	70 mV (MM, 1 kHz 0.5%)
S/N Ratio (Line, IHF-A)	106 dB	106 dB
S/N Ratio (Phono MM, IHF-A)	80 dB	80 dB
Frequency Response (Analog In)	5 Hz - 100 kHz/+1 dB, -3 dB (Direct/Pure Audio)	5 Hz - 100 kHz/+1 dB, -3 dB (Direct/Pure Audio)
DSD Sampling Rates via HDMI	2.8 MHz	2.8 MHz
DSD Sampling Rates via USB	2.8 MHz, 5.6 MHz, 11.2 MHz	2.8 MHz, 5.6 MHz, 11.2 MHz
Video Input Sensitivity/Output Level and Impedance	1 Vp-p/75 Ω (Component Y) 0.7 Vp-p/75 Ω (Component PB/CB, PR/CR) 1 Vp-p/75 Ω (Composite)	1 Vp-p/75 Ω (Component Y) 0.7 Vp-p/75 Ω (Component PB/CB, PR/CR) 1 Vp-p/75 Ω (Composite)
Ethernet Standard	10BASE-T/100BASE-TX	10BASE-T/100BASE-TX
Wi-Fi Standard	IEEE 802.11 a/b/g/n/ac	IEEE 802.11 a/b/g/n
Wi-Fi Terminal Frequency	5 GHz, 2.4 GHz	5 GHz, 2.4 GHz
Bluetooth Version	4․2	4․2
Bluetooth Frequency	2.4 GHz	2.4 GHz
USB Terminal	Ver. 2.0, 5 V, 1 A	Ver. 2.0, 5 V, 1 A
FM Frequency	87.5 MHz - 107.9 MHz	87.5 MHz - 107.9 MHz
FM 50 dB Quiet Sensitivity (IHF, 1 kHz, 100% MOD.)	Mono: 1.0 µV (11.2 dBf)	Mono: 1.0 µV (11.2 dBf)
AM Frequency	530 kHz - 1710 kHz	530 kHz - 1710 kHz
Warranty	3 Years	3 Years

* - 480i/576i and 480p/576p only
** - 480i/576i only
*** - no 1080p/24 upconversion
**** - 1080p signal is not converted
